LuK DMF175 - Clutch Flywheel LuK DMF175
$46849
In stock
limited availability at this price!
. Learn more
LUK part description
Product Description
LuK DMF Manu
Application Summary
Hyundai Santa Fe 2010-2012 (L4, 2.4L), Hyundai Sonata 2011-2012 (L4, 2.4L), Kia Optima 2011-2012 (L4, 2.4L), Kia Sorento 2011 (L4, 2.4L)
Product Attributes
| Dowel hole diameter | 0.315 inch |
| Dowel hole diameter | 8 mm |
| Flange Thickness | 0.415 inch |
| Flange Thickness | 10.54 MM |
| Crank Hole Dia. | 0.4882 inch |
| Crank Hole Dia. | 12.4 mm |
| Dowel Hole Pattern | 5 |
| Ring Gear Thickness | 0.5504 inch |
| Ring Gear Thickness | 13.98 mm |
| Number of teeth, starter ring gear | 110 |
| Ring Gear Major Dia. | 11.072 inch |
| Ring Gear Major Dia. | 281.23 mm |
| Bolt hole PCD clutch pres.plte | 10.2362 inch |
| Bolt hole PCD clutch pres.plte | 260 mm |
| Ring Gear Chamfer matches OE | Ring Gear Chamfer matches OE |
| Bolt Hole Pattern | 2 |
| Crank To Friction Surface | 1.3461 inch |
| Crank To Friction Surface | 34.19 mm |
| Flywheel Thickness [mm] | 2.3465 inch |
| Flywheel Thickness [mm] | 59.6 mm |
| I.D. for Pilot | 1.5937 inch |
| I.D. for Pilot | 40.48 mm |
| Cup depth, secondary flywheel | -0.6248 inch |
| Cup depth, secondary flywheel | -15.87 mm |
| Ring Gear To Friction Surface | 0.9606 inch |
| Ring Gear To Friction Surface | 24.4 mm |
| Bolt hole PCD crankshaft | 2.5854 inch |
| Bolt hole PCD crankshaft | 65.67 mm |
| Centering diameter / dowel hole | 10.2362 inch |
| Centering diameter / dowel hole | 260 mm |
| Ring Gear Mounting O.D. | 10.1012 inch |
| Ring Gear Mounting O.D. | 256.57 mm |
| Flywheel friction surface outer diameter | 9.5669 inch |
| Flywheel friction surface outer diameter | 243 mm |
| Overall Casting O.D. | 10.9047 inch |
| Overall Casting O.D. | 276.98 mm |
| Flywheel Friction Surface Inner diameter | 5.8268 inch |
| Flywheel Friction Surface Inner diameter | 148 mm |
Additional Information
| Remanufactured Part | N |
| Warranty Special | 12 Months or 12,000 miles, Whichever comes first |
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8483508080 |
| Stock Status | S |
| UPC | 00670774369544 |
Part Interchanges
Fits Vehicles
- Kia Optima (2011-2012)
- Hyundai Sonata (2011-2012)
- Kia Sorento (2011)
- Hyundai Santa Fe (2010-2012)
LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
