(888) 312-8812 Login SignupSTANDARD IGNITION S2154 Multi Function Connector
Tap to view 2 more
$3249
Limited availability at this price!
5 Day Lead Time
Get it by Thursday, Jan 8
STANDARD IGNITION S2154 Part Description
Manufacturer
Product Description
Multi Function Connector
Features & Benefits
- Protective Tubing Included
- Each part has high-quality direct replacement electrical connector that eliminates the need for a harness, replacing only the damaged connector, for a cost effective repair solution
- The terminals are manufactured with high grade materials such as copper alloy, brass, and phosphor bronze.
- The Housing is fabricated using polyamide resins. All of the materials together provide the connectors with prolonged life and superior performance in harsh environments.
- All electrical connectors are 100% tested for proper mechanical and electrical fit, form and function.
- Offering thousands of high-quality pigtails and sockets for nearly every electrical job.
STANDARD IGNITION S2154 Specifications
Product Attributes
| Attachment Method | Push On |
| Bend Angle (Deg.) | 0 |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Connector Shape | Polygon |
| Contact Terminal Material | Metal |
| Dust Shield Included | No |
| Length - Inches | 1.375 |
| Material | Plastic |
| Number Of Splice Connectors Includ | 2 |
| Number of Wires | 2 |
| Splice Connectors Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 2 |
| Terminal Type | Pin |
| Water Resistant | No |
| Weatherproof Sealed | Yes |
| Wire Gauge (ga) | 14 |
| Wire Quantity | 2 |
| Wiring Harness Included | Yes |
| Wiring Harness Length (in) | 13 |
| Wiring Harness Length (mm) | 330.2 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8536908585 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086092249 |
STANDARD IGNITION S2154 Part Interchanges
| Brand | Part Number |
|---|---|
| Echlin | EC2056 |
| Motorcraft | WPT474 |
| BWD | PT2142 |
| Ford | 3U2Z14S411NFA |
| N/A | 1P4111, PTA2827, CONB11197 |
STANDARD IGNITION S2154 Fits Vehicles
- Mercury Grand Marquis (1993-1995)
- Ford Thunderbird (1997)
- Ford Explorer Sport (2001-2003)
- Ford F-450 Super Duty (2010-2016)
- Ford F-550 Super Duty (2010-2016)
- Ford F-350 Super Duty (2010-2016)
- Ford F-250 Super Duty (2010-2016)
- Lincoln Mark LT (2006-2008, 2010-2014)
- Ford Explorer Sport Trac (2001-2005)
- Mercury Sable (1992-1999)
- Mercury Mountaineer (1997-2005)
- Lincoln Navigator (1998-2002)
- Lincoln Continental (1993, 1996-2002)
- Ford Windstar (1995-2003)
- Ford Taurus (1992-2007)
- Ford Ranger (1995-2010)
- Ford Mustang (2000, 2002-2004)
- Ford F-350 (1993-1997)
- Ford F-250 (1993-1997)
- Ford F-150 (1993-2014)
- Ford F-Super Duty (1993-1997)
- Ford Explorer (1993-2005, 2009-2010)
- Ford E-250 (2003-2004)
- Ford E-150 (2002-2004)
- Ford Crown Victoria (1993-1995)
- Ford Aerostar (1992-1995)
