*Representative image - actual part not displayed
Centric 120.86028 - Centric Premium Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 37.000 |
| Disc Mounting [cntrc] | Behind the Hub |
| Weight [cntrc] Kgs | 81.400 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Notes [cntrc] | U Shaped |
| Discard Thickness | 1.457 IN |
| Discard Thickness | 37.000 MM |
| Nominal Thickness | 45.000 MM |
| Nominal Thickness | 1.772 IN |
| Overall Height | 5.320 IN |
| Overall Height | 135.128 MM |
| Outside Diameter | 432.054 MM |
| Outside Diameter | 17.010 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 134.900 MM |
| Center Hole Diameter | 5.311 IN |
| Mounting Bolt Hole Circle Diameter | 9.250 IN |
| Mounting Bolt Hole Circle Diameter | 234.950 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590377200 |
Part Interchanges
Fits Vehicles
- MAN TGS (2015-2017)
- MAN TGX (2015-2018)
