Delphi TC5008 - Ball Joint
$4899
5 day lead time
limited availability at this price!
Pay over 3-12 months with . Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
Item Grade | Standard Replacement |
Position(s) | Front Right |
Material | Steel |
Maximum Outside Diameter | 1.906 IN |
Maximum Outside Diameter | 48.4 MM |
Color | Black |
Stud Thread Diameter | 0.551 IN |
Stud Thread Diameter | 14.0 MM |
Castle Nut Included | Yes |
Grease Fitting Included | No |
Suspension Grade Type | Standard |
Bushings Included | No |
Dust Boot Included | Yes |
Ball Joint Assembly | Yes |
Width | 88.8 MM |
Cotter Pin Included | Yes |
Cotter Pin Hole | Yes |
Mounting Hardware Included | Yes |
3068 | 1.634 IN |
Mounting Bolt Length | 41.5 MM |
Washers Included | No |
Height | 4.248 IN |
Height | 107.9 MM |
Nuts Included | Yes |
Mounting Hole Quantity | 3 |
Adjustable | No |
Greasable | No |
4966 | 0.906 IN |
Stud Thread Length | 23.0 MM |
839 | 16.0mm |
Stud Type | Threaded |
Distance Between Mounting Holes | 50.0 MM |
Dust Boot Material | Choloroprene Rubber (CR) |
9202 | 0.472 IN |
Mounting Bolt Shank Diameter | 12.0 MM |
9203 | 1.047 IN |
Mounting Bolt Head Diameter | 26.6 MM |
Mounting Bolts Included | Yes |
Mounting Bolt Thread Pitch | 1.25 MM |
9207 | 1.181 IN |
Mounting Bolt Thread Length | 30.0 MM |
Mounting Bolt Thread Diameter | 12.0 MM |
Mount Plate Included | No |
Tapered Stud | Yes |
9212 | 0.829 IN |
Stud Tapered End 2 Diameter | 21.05 MM |
9213 | 0.697 IN |
Stud Tapered End 1 Diameter | 17.7 MM |
Stud Thread Pitch | 1.5 MM |
Additional Information
Harmonized Tariff Code (Schedule B) | 8708807000 |
Harmonized Tariff Code (HTS) | 8708806590 |
Warranty Special | Limited Lifetime |
Warranty Special UOM | LF |
Country of Origin (Primary) | TR |
UPC | 00689604283134 |
VMRS Code | 016001015 |
UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Lexus RX450hL (2018-2021)
- Lexus RX350L (2018-2021)
- Toyota Venza (2009-2015)
- Toyota Sienna (2011-2020)
- Lexus RX450h (2010-2021)
- Lexus RX350 (2010-2021)
- Toyota Highlander (2008-2019)
