WABCO 4235061860 - Air Brake Chamber - Unistop Series, Disc Brakes
$12249
30 day lead time
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
Brake Chamber (Disc Brake)
Product Attributes
| Weight | 0.0022046 |
| Type | 24 |
| Max. operating pressure | 10.2 bar |
| Port threads | 3/8" - 18 NPTF |
| Bolt Lengths | 38.5 mm |
| Temperature Range | -40°C to +80°C |
| Distance between bolts | 120.6 mm |
| Type Of Operation | Disc |
| Total Length | 121.0 mm |
| Version | Without boot |
| Return-Spring Force | 190 N |
| Push-rod thread | Ball R8 |
| Stroke | 65.0 mm |
| Bolt Threads | M16 x 1.5 |
| Push-Rod Length | 15 mm |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
