TrakMotive MI8171 - CV Axle Shaft
- Part Number
- MI8171
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$8249
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 48 |
| ABS Ring Type | Magnetic |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .75 |
| Axle Nut Height (mm) | 19 |
| Axle Nut Hex Size (in) | 1.25 |
| Axle Nut Hex Size (mm) | 32 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 35 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M22x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Female |
| Inboard Shaft Connection Style | Female |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 34 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 27 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 22.83 |
| Overall Compressed Length (mm) | 580 |
| Axle Nut Socket Size | 32 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084051714 |
Part Interchanges
- EMPI 80-2031
- USA Industries 7086389
- USA Industries AX-86389
- Diversified Shafts Solutions 2112N
- Drive Tech America DC-2131
- CARDONE Reman 60-3557
- CARDONE Reman 66-3557
- CARDONE Reman MP3557
- IMC 40714008
- Carquest Premium AC NCV479098
- OEM Part Number 4578601AA
- ODM CH-8-8590A
- TrakMotive MI-8171
- ProTech CH10535
- NCV479098
- NCV12508
- 72033
- 239171
TRAKMOTIVE MI8171 Cross Reference
We have 1 alternatives for the MI8171 by TRAKMOTIVE:
Fits Vehicles
- Dodge Challenger (2017-2020)
- Dodge Charger (2007-2020)
- Chrysler 300 (2005-2020)
- Dodge Magnum (2005-2008)
