Delphi TA5348 - Tie Rod End
$2949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Inner, Left Inner. For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Length | 213.00 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 43 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.625 IN |
| End 2 Thread Diameter | 15.88 MM |
| Height | 90.80 MM |
| Housing Material | Steel |
| 36 | 0.787 IN |
| Tube Diameter | 20.00 MM |
| Adjustable | No |
| Greasable | Yes |
| Weight | 1.54 lb |
| Cone Outside Diameter | 19.10 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| Length Stud Center to End | 7.480 IN |
| Length Stud Center to End | 190.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 18 |
| End 1 Threads Per Inch | 18 |
| End 1 Thread Diameter | 0.625 IN |
| End 1 Thread Diameter | 15.88 MM |
| Shank Length | 19.10 MM |
| Stud Length | 19.10 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.752 IN |
| Stud Length | 0.752 IN |
| 662 | 0.752 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604289266 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- GMC 1000 (1966)
- Chevrolet C20 Panel (1967)
- Chevrolet C30 Panel (1965-1966)
- Chevrolet G30 Van (1970)
- GMC P35/P3500 Van (1968-1970)
- GMC P25/P2500 Van (1968-1970)
- GMC C35/C3500 Pickup (1967-1970)
- GMC C25/C2500 Pickup (1967-1970)
- Chevrolet P30 Van (1968-1970)
- Chevrolet P20 Van (1968-1970)
- Chevrolet C30 Pickup (1965-1970)
- Chevrolet C20 Suburban (1967-1970)
- Chevrolet C20 Pickup (1965-1970)
