Name: Delphi TA5329 Tie Rod End
SKU: ta5329
Price: 97.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Right Outer
Item Grade	Standard Replacement
Length	1207.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	Yes
Dust Boot Included	Yes
Width	51 MM
Type	Straight
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.875 IN
End 2 Thread Diameter	22.23 MM
Height	97.00 MM
Housing Material	Steel
36	1.024 IN
Tube Diameter	26.00 MM
Adjustable	No
Greasable	Yes
Weight	17.41 lb
Cone Outside Diameter	19.65 MM
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Stud Type	Threaded
Length Stud Center to End	46.496 IN
Length Stud Center to End	1181.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 2 Threads Per Inch	18
End 1 Threads Per Inch	18
End 1 Thread Diameter	0.563 IN
End 1 Thread Diameter	14.29 MM
Shank Length	19.65 MM
Stud Length	19.65 MM
Grade Type	Standard
Grade	Premium
Shank Length	0.774 IN
Stud Length	0.774 IN
662	0.774 IN

Additional Information

Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Harmonized Tariff Code (Schedule B)	8708998175
Country of Origin (Primary)	TR
UPC	00689604289129
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Jeep Wagoneer (1974-1983)
Jeep Grand Wagoneer (1984-1991)
Jeep Cherokee (1974-1983)
