Need help? We're here!
(888) 312-8812 Login SignupDELPHI TA3189 Tie Rod End
Tap to view 2 more
$4149
Limited availability at this price!
In Stock
Get it by Friday, Jan 2
DELPHI TA3189 Part Description
DELPHI TA3189 Specifications
Product Attributes
| Position(s) | Left Outer |
| Item Grade | Standard Replacement |
| Color | Black |
| End 1 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 49.3 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.00 MM |
| Height | 94.70 MM |
| Grade Type | Standard |
| Housing Material | Steel |
| Tube Diameter | 0.886 IN |
| Tube Diameter | 22.50 MM |
| Adjustable | No |
| Weight | 1.85 lb |
| Cone Outside Diameter | 15.50 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 7.343 IN |
| Length - Stud Center to End | 186.50 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 12.00 MM |
| Shank Length | 15.50 MM |
| Stud Length | 15.50 MM |
| Grade | Premium |
| Shank Length | 0.610 IN |
| Stud Length | 0.610 IN |
| Cone Outside Diameter | 0.610 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604284612 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
DELPHI TA3189 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-7671 |
| MOOG Chassis Products | ES800842 |
| Toyota | 45047-49165 |
| MAS Industries | TO74201, TO74201XL, 531072 |
| TRW | JTE7814 |
| N/A | MS86637, 531072 |
DELPHI TA3189 Fits Vehicles
- Toyota Prius Plug-In (2012-2015)
- Lexus CT200h (2011-2017)
- Toyota Prius (2010-2015)
DELPHI TA3189 Customer Reviews
No reviews yet
Be the first to review this product!
