Name: NGK Spark Plugs 92274 NGK Ruthenium HX High Ignitability Spark Plug
SKU: 92274
Price: 12.99 USD
Availability: InStock

NGK SPARK PLUGS part description

Product Description

NGK Ruthenium HX High Ignitability Spark Plug

Features & Benefits

HIGH IGNITABILITY DOUBLE FINE ELECTRODE DESIGN: Combines 0.6 millimeter ruthenium center with opposed fine wire platinum ground electrode
RUTHENIUM ALLOY CENTER ELECTRODE: NGK's patented ruthenium technology produces maximum performance, ignitability & durability at high temperatures
PLATINUM PIN TYPE GROUND ELECTRODE: Provides more complete fuel burn, quicker throttle response, smoother idle and better cold starts
SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
RECOMMENDED USAGE: Modern vehicles using OE DFE type spark plugs or for those seeking an aftermarket plug with the latest OE technology

Product Attributes

Part Number	LKAR7AHX-S
Stock Number	92274
Resistance	5000.0 82
Ground Electrode Tip Design	Dual Fine Electrode (DFE) - High Ignitability
Ground Configuration	J-Gap
Ground Electrode Core Material	Nickel
Electrical Terminal Type	Non-Removable Nut
Center Electrode Core Material	Copper
Center Electrode Tip Material	Ruthenium
Pre-Gap Size	.044 IN
Ground Electrode Quantity	1
Hex Size	14 MM
Insulator Height	51.00 MM
Manufacturer Heat Range	7
Seat Type	Flat
Reach	26.5 MM
Thread Diameter	12.00 MM
Short Style Spark Plug	No
Service Number	LKAR7AHX-S
Washer Included	Yes
Grade Type	Performance
Hex Size	14mm
Insulator Height	1.99 IN
Reach	1.043 IN
Thread Diameter	0.472 IN
Insulator Material	Ceramic
Resistor Type	Yes
6648	0.0 IN
Ground Electrode Tip Material	Platinum
9459	No
9506	0.12 IN
9608	Fine Wire
9745	Crush
9805	Mid Projection

Additional Information

Warranty Time UOM	MO
Warranty Time	2
Country of Origin (Primary)	JP
Harmonized Tariff Code (HTS)	8511100000
UPC	00087295922743
VMRS Code	033003005
UNSPSC	26101732

Part Interchanges

Fits Vehicles

Mazda CX-90 (2024)
Honda HR-V (2023-2025)
Mazda CX-50 (2023-2024)
Mazda CX-30 (2020-2024)
Nissan Frontier (2020-2024)
Nissan NV3500 (2018-2021)
Nissan NV2500 (2018-2021)
Toyota Yaris iA (2017-2018)
Nissan TITAN (2017-2024)
Nissan Armada (2017-2024)
Toyota Prius Plug-In (2012-2015)
Honda Civic (2016-2024)
Nissan TITAN XD (2016-2024)
Subaru Crosstrek (2016-2017)
Scion iA (2016)
Mazda CX-3 (2016-2022)
Mazda MX-5 Miata (2016-2023)
Toyota Yaris (2016-2020)
Acura ILX (2016-2022)
Acura TLX (2015-2020)
INFINITI Q70L (2015-2019)
Honda CR-V (2015-2019)
Honda Fit (2015-2019)
INFINITI Q70 (2014-2019)
INFINITI QX70 (2014)
INFINITI QX60 (2014-2020, 2022-2024)
INFINITI QX80 (2014-2024)
INFINITI Q50 (2014-2018)
Mazda 6 (2014-2021)
Nissan Pathfinder (2013-2024)
Honda Accord (2013-2017)
Subaru XV Crosstrek (2013-2015)
Subaru Outback (2013-2019)
Subaru Legacy (2013-2019)
INFINITI JX35 (2013)
Mazda CX-5 (2013-2023)
Scion iQ (2012-2014)
Mazda 3 Sport (2011-2024)
Mazda 3 (2012-2024)
Toyota Prius V (2012-2015)
Subaru Impreza (2012-2016)
INFINITI M35h (2012-2013)
Lexus CT200h (2011-2015)
Nissan Quest (2011-2017)
Subaru Forester (2011-2018)
INFINITI G25 (2011-2012)
INFINITI QX56 (2011-2013)
INFINITI M56 (2011-2013)
Toyota Prius (2010-2015)
INFINITI M35 (2009-2010)
Nissan Maxima (2009-2014, 2016-2023)
INFINITI FX50 (2009-2013)
INFINITI FX35 (2009-2012)
Nissan Murano (2009-2024)
Pontiac Vibe (2009-2010)
Toyota Matrix (2009-2014)
Toyota Corolla (2009-2015)
INFINITI EX35 (2008-2012)
Scion xD (2008-2014)
Nissan 350Z (2007-2009)
INFINITI G35 (2007-2008)
Nissan Altima (2007-2018)
