TrakMotive FD8172 - CV Axle Shaft
- Part Number
- FD8172
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$11949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | N/A |
| ABS Ring Type | N/A |
| Abs Tone Ring Included | No |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | 2/5 |
| Axle Nut Height (mm) | 10.5 |
| Axle Nut Hex Size (in) | 5/9 |
| Axle Nut Hex Size (mm) | 14 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 5/8 |
| Axle Nut Length (mm) | 16 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M10*1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | N/A |
| Number Of Inboard Joint Bolt Holes | N/A |
| Number Of Inboard Shaft Bolts | N/A |
| Number Of Inboard Splines | 31 |
| Number Of Outboard Joint Bolt Holes | N/A |
| Number Of Outboard Shaft Bolts | N/A |
| Number Of Outboard Splines | 45 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Spline |
| Overall Compressed Length (in) | 24.92 |
| Overall Compressed Length (mm) | 633 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084021724 |
Part Interchanges
- EMPI 80-2941
- USA Industries AX-8786
- Diversified Shafts Solutions 8305N
- CARDONE Reman 60-2191
- CARDONE Reman 60-2237
- CARDONE Reman 66-2191
- Carquest Premium AC NCV428573
- OEM Part Number 7L1Z3B437A
- OEM Part Number AL1Z3A427A
- OEM Part Number AL1Z3A427B
- OEM Part Number TX474
- OEM Part Number TX577
- OEM Part Number TX582
- ODM FD-8-8719
- TrakMotive FD-8172
- ProTech FD10553
- NCV428573
- 66-2191HD
- NCV11158
- 71174
- 169172
TRAKMOTIVE FD8172 Cross Reference
We have 2 alternatives for the FD8172 by TRAKMOTIVE:
Fits Vehicles
- Lincoln Mark LT (2010-2014)
- Ford Lobo (2009-2015)
- Ford F-150 (2009-2014)
- Lincoln Navigator (2007-2017)
- Ford Expedition (2007-2017)
