Name: TrakMotive CH8112 CV Axle Shaft
SKU: ch8112
Price: 100.49 USD
Availability: InStock

TRAKMOTIVE part description

Product Description

CV Axle Shaft

Product Attributes

ABS Ring Tooth Count	N/A
ABS Ring Type	N/A
Abs Tone Ring Included	No
Axle Bolt Hex Size (mm)	N/A
Axle Bolt Length (mm)	N/A
Axle Bolt Thread Size	N/A
Axle Nut Head Type	Hex
Axle Nut Height (in)	3/5
Axle Nut Height (mm)	15
Axle Nut Hex Size (in)	1 1/4
Axle Nut Hex Size (mm)	32
Axle Nut Included	Yes
Axle Nut Length (in)	1 1/2
Axle Nut Length (mm)	37
Axle Nut Locking Type	Cotter Pin
Axle Nut Thread Size	M22*1.5
Boot Material	Neoprene
Inboard Bolt Head Size (in)	N/A
Inboard Bolt Head Size (mm)	N/A
Inboard Bolt Head Type	N/A
Inboard Bolt Length (in)	N/A
Inboard Bolt Length (mm)	N/A
Inboard Bolt Thread Size	N/A
Inboard Joint Type	Male
Inboard Shaft Connection Style	Male
New Or Remanufactured	New
Number of Bolt Holes	N/A
Number Of Inboard Joint Bolt Holes	N/A
Number Of Inboard Shaft Bolts	N/A
Number Of Inboard Splines	27
Number Of Outboard Joint Bolt Holes	N/A
Number Of Outboard Shaft Bolts	N/A
Number Of Outboard Splines	28
Outboard Bolt Head Size (in)	N/A
Outboard Bolt Head Size (mm)	N/A
Outboard Bolt Head Type	N/A
Outboard Bolt Length (in)	N/A
Outboard Bolt Length (mm)	N/A
Outboard Joint Bolt Thread Size	N/A
Outboard Joint Type	Conventional
Outboard Shaft Connection Style	Spline
Overall Compressed Length (in)	37.72
Overall Compressed Length (mm)	958

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8708508500
UPC	00844084011121

Part Interchanges

TRAKMOTIVE CH8112 Cross Reference

We have 1 alternatives for the CH8112 by TRAKMOTIVE:

APW INTERNATIONAL CH8369

Fits Vehicles

Jeep Patriot (2007-2017)
Jeep Compass (2007-2017)
Dodge Caliber (2007-2012)
