Rancho RS55262 - Rancho RS5000X RS55262 Shock Absorber
$8049
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
RANCHO part description
Product Description
RS5000X Suspension Shock Absorber
Features & Benefits
- IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE -- Features a 16mm nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
- SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE -- Nitrogen gas pressurized to 150 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
Product Attributes
Compressed Length | 15.08 IN |
Travel Length | 8.81 in |
Finish | Painted |
Grade Type | Performance |
Extended Length | 23.89 in |
Gas Charged | Yes |
Adjustable Damping | No |
Dust Shield Included | Yes |
9783 | No |
9789 | LS47 |
9791 | LS47 |
9792 | No |
9801 | 35 MM |
9908 | No |
Body Diameter | 2.188 |
Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
Part Description | Shock Absorber |
Parts Pack(s) | None |
Upper Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
Additional Information
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
MSDS Sheet Number | 01164 |
UPC | 00039703005845 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Rancho RS5262
- ACDelco 540435
- ACDelco 580458
- Gabriel 77953
- Monroe Shocks & Struts 911103
- Monroe Shocks & Struts 911150
- Monroe Shocks & Struts 911166
- Monroe Shocks & Struts 911506
- Monroe Shocks & Struts 37105
- Monroe Shocks & Struts 37150
- Monroe Shocks & Struts 37166
- Monroe Shocks & Struts 34676
- Monroe Shocks & Struts 34692
- Monroe Shocks & Struts 34777
- KYB 344436
- KYB 3450006
- KYB 565103
- KYB KG5195
- General Motors 20955408
- General Motors 20955409
- General Motors 20955430
- General Motors 22811845
- General Motors 22811846
- General Motors 22811847
- General Motors 23183849
- General Motors 23183851
- General Motors 23425614
- General Motors 23425615
- General Motors 84082039
- General Motors 84082041
- General Motors 84082042
- General Motors 84082043
- Sensen 12140170
- Unity Automotive 251400
- AL-KO Xtreme 813010
- FCS 342476
- FCS 342572
Fits Vehicles
- Chevrolet C1500 (2002)
- Chevrolet Suburban 3500 HD (2016-2019)
- GMC Sierra 3500 Classic (2007)
- GMC Sierra 1500 Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- Chevrolet Silverado 1500 Classic (2007)
- GMC Yukon XL (2015-2020)
- Chevrolet Suburban (2015-2020)
- GMC Sierra 3500 HD (2007-2010)
- Chevrolet Silverado 3500 HD (2007-2010)
- Chevrolet Avalanche (2007-2013)
- GMC Yukon XL 2500 (2000-2013)
- GMC Yukon XL 1500 (2000-2014)
- GMC Yukon (2000-2020)
- GMC Sierra 3500 (2001-2006)
- GMC Sierra 1500 (1999-2006)
- Chevrolet Tahoe (2000-2020)
- Chevrolet Suburban 2500 (2000-2013)
- Chevrolet Suburban 1500 (2000-2014)
- Chevrolet Silverado 3500 (2001-2006)
- Chevrolet Silverado 1500 (1999-2006)
- Chevrolet Avalanche 2500 (2002-2006)
- Chevrolet Avalanche 1500 (2002-2006)
- Dodge Ram 2500 (1994-2002)
- Dodge Ram 1500 (1994-2001)
