Name: Wagner BD125039E Wagner Brake BD125039E Disc Brake Rotor
SKU: bd125039e
Price: 46.99 USD
Availability: InStock

WAGNER part description

Product Description

Disc Brake Rotor

Application Summary

1990-1999 Jeep Cherokee (Front) (Drive: 4WD / Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion, Composite Rotor, Height 2-31/32 (in)); 1990-1992 Jeep Comanche (Front) (Drive: 4WD / Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 1993-1998 Jeep Grand Cherokee (Front) (Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 1993 Jeep Grand Wagoneer (Front) (Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 1990 Jeep Wagoneer (Front) (Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 1990-1999 Jeep Wrangler (Front) (Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion, Composite Rotor, Height 2-31/32 (in)); 1997-1999 Jeep TJ (Front) (Qualifier: 5 Stud Wheel, Full Cast Rotor, Replaces OE, with 280 (mm) Diameter Brake Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion)

Features & Benefits

ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance

Product Attributes

Material	Cast Iron
Nominal Thickness	24.2 MM
Disc Finish	Directional
Construction	Full Cast
Rust Resistant Coating	Yes
Outside Diameter	280.1 MM
Surface Type	Smooth
Solid Or Vented Type Rotor	Vented
Height	81.3 MM
Part Description	Disc Brake Rotor
Nominal Thickness	0.955 IN
Height	3.204 in

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (Schedule B)	8708305030
Harmonized Tariff Code (HTS)	8708305030
UPC	00008536948087
VMRS Code	013017001
UNSPSC	25171705

Part Interchanges

When it comes to high-quality lighting and braking products for vehicle safety systems, one name stands out—Wagner®. Since 1891, this brand has been developing highly efficient critical components for vehicle safety systems across the globe. Wagner® is renowned for its cutting-edge braking component and technologies for passenger cars and medium-duty and commercial applications. This brand is also at the forefront of lighting products manufacturing since the introduction of the sealed-beam headlamp. Wagner brake parts and lighting products set high industry standards, thanks to its over 125 years of manufacturing experience and engineering expertise and its commitment to developing products that deliver superior performance.

Fits Vehicles

Jeep TJ (1997-1999)
Jeep Wrangler (1990-1995, 1997-1999)
Jeep Wagoneer (1990)
Jeep Grand Wagoneer (1993)
Jeep Grand Cherokee (1993-1998)
Jeep Comanche (1990-1992)
Jeep Cherokee (1990-1999)
