REDNECK TRAILER K23-533-00 Part Description
Manufacturer
Fits AL-KO Hayes Axle. Right hand 12" x 3-3/8" 8,000lbs(per pair) electric brake assembly. 1 - Right Hand 12" x 3-3/8 Complete Brake Assembly (ready to bolt on and wire in). Mounting bolts and nuts included. In 1995 the brake was redesigned to use a ventilated magnet, replacing the round magnet.
- Fits AL-KO/Hayes 8,000lb axle with a 4 bolt pattern on the mounting flange.
- Right Hand
- Passenger's side
- Complete assembly
- For use with a 12" inside diameter and 3 3/8" deep drum
- The shoes are 3 3/8" wide
- Self adjusting
Please refer to the diagram Image for these measurements
To determine the size of the brake, you need 2 measurements. The first is the diameter of the brake(D). The second is the width of the shoe(W). It is good to take note of how many mounting bolts the brake has.
