WABCO 4722500000 Part Description
Manufacturer
WABCO Brake Proportioning Valve
An empty trailer needs less rear braking force than a fully loaded one, which is exactly the gap the WABCO Brake Proportioning Valve closes. This pneumatic valve modulates air pressure heading to the rear brake chambers, holding back excess force during unladen runs. Load distribution feeds directly into that adjustment, so braking force scales up or down as cargo weight changes. Tire wear drops along with premature rear-wheel lockup once pressure matches the load riding on the axle. Cleared for operation up to 10.0 bar, the WABCO 4722500000 fits directly into standard commercial pneumatic brake circuits.
Proportional Valve
Features & Benefits
- Modulates rear brake pressure based on real-time load distribution
- Adjusts automatically without requiring any driver input or setup
WABCO 4722500000 Specifications
Product Attributes
| Weight | 1.4198 |
| Calculated Volume (dm³) | 0.487 |
| Multi Nominal Diameter (From Port 1 To X) | 4.0 / 2.5 mm |
| Temperature Range | -40°C to +80°C |
| Nominal Diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Voltage | 24 V |
| Distance Between Holes | 42 mm |
| Electrical connection | M 27x1 |
| Mounting | 2x Ø 9.0 mm |
| Max. operating pressure | 10.0 bar |
| Port thread 2 | M12 x 1.5 |
| Max. operating pressure | 10.0 bar |
| Rated current | 570 mA |
| Type | Proportional valve |
| Size | 61 x 121 x 66 |
WABCO 4722500000 Cross References
| Brand | Part Number |
|---|---|
| 125736, 98465149, 500005186, 5010135774 | |
| ALEXANDER DENNIS | 655586, 6538773 |
| DAF | 1505432 |
| DIMETAL | 4407199 |
| ERF | 1170242 |
| EVOBUS | A6644297082 |
| IRISBUS | 500005186, 4460001016 |
| IVECO | 4460001016, 5010135774, E4460001016, 500005186, 98465149 |
| KENWORTH | S472-250-000-0 |
| LEYLAND-DAF | 1257361, 125736 |
| MAFI | 0005516042 |
| MAN | 79100580415, 1170242, N2509990040 |
| MERCEDES-BENZ | 6644297082, A6644297082, 8133302, 1335961 |
| MERITOR | S4722500000 |
| PACCAR | 1505432 |
| PETERBILT | S472-250-000-0 |
| RENAULT | 5010135774 |
| SCANIA | 1335961, 6644297082, 1934980, 8133302 |
| STEYR | 79100580415 |
| UD TRUCKS | 4760000Z08. |
| VDL BUS | 219125, 20219125 |
| VOLVO | 1335961, 6644297082, 8133302, 3127660 |
WABCO 4722500000 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4722500000 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
