(888) 312-8812 Login SignupWABCO 4712000080 Air Brake Control Valve
Tap to view 3 more
MSRP: $1,389.90
$1,04899
Save $340.91
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4712000080 Part Description
Manufacturer
WABCO Air Brake Control Valve
Set at an operating pressure of 8.0 bar, the WABCO Air Brake Control Valve manages the air signal that governs a conventional air brake system's behavior. Its 117 x 117 mm bolt spacing matches a standard mounting pattern, so the valve bolts to the chassis without needing a custom bracket. At 4.46 kilograms, it carries enough mass to stay planted under the vibration of a rough road without working itself loose. Built for conventional air brake architectures, the WABCO 4712000080 handles the control function a standard commercial system depends on.
Trailer Control Valve
Features & Benefits
- Internal components resist corrosion from years of exposure to road spray
- Holds its calibration steady across seasonal temperature swings throughout the year
WABCO 4712000080 Specifications
Product Attributes
| Version | 1 Circuit |
| Size | 145 x 146 x 205 |
| Temperature Range | -40°C to +80°C |
| Mounting | 4x M10 |
| Port thread 4 | M22 x 1.5 |
| Max. operating pressure | 8.0 bar |
| Distance between bolts | 117x117 mm |
| Calculated Volume (dm³) | 4.3398 |
| Weight | 4.4599 |
| Port thread 2 | M22 x 1.5 |
| Port thread 1 | M22 x 1.5 |
WABCO 4712000080 Cross References
| Brand | Part Number |
|---|---|
| CASE IH | 820062500, 3224925R91 |
| DAF | 583512, 0583512, 577677 |
| DEUTZ | 02382049, 2382049 |
| EVOBUS | A0004314905 |
| FAUN | 99700303799, 1617091 |
| FENDT | 385880020060, F250882020090 |
| FORD | 75HB2K422DA, 75HB2K422AA |
| FREIGHTLINER | TDAS4712000080 |
| IVECO | 03435116, 02519881, 04677470, 03420702, 4677470 |
| JOHN DEERE | AL68577 |
| KENWORTH | S4712000080 |
| LIEBHERR | 5029664 |
| MACK | 6300-4712000080 |
| MAFI | 0005661002, 5661002 |
| MAN | 88523016204, 81523016015, 81523016044, 90810112133, 81523016028, 81523016141, 81523016169, 88521806204 |
| MERCEDES-BENZ | 0014312605, 0014310705, 0004314905, 0004318705, A0004314905 |
| MERITOR | S4712000080 |
| NEOPLAN | 81523016015 |
| PETERBILT | S4712000080 |
| PPT | 5234200080 |
| RENAULT | 24653053, 0024653053, 5000012631, 5000242207 |
| SCANIA | 2090296 |
| STEYR | 89000360405, 89000360403, 88000360135 |
| TEREX-DEMAG | 30089340 |
| VOLVO | WAB4712000080, 348486 |
| WABCO | S4712000080 |
