Centric 123.62008 - C-Tek Standard Brake Drum
$5399
MSRP: $59.64
Save: $5.65
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 8.636 |
| Weight [cntrc] Lbs | 19.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Hub Hole / Register [cntrc] Mm | 71.374 |
| Hub Hole / Register [cntrc] In | 2.810 |
| Height [cntrc] Mm | 89.408 |
| Height [cntrc] In | 3.520 |
| Friction Surface Width [cntrc] Mm | 61.214 |
| Friction Surface Width [cntrc] In | 2.410 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 294.894 MM |
| Outside Diameter | 11.610 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 11.430 MM |
| Mounting Hole Diameter | 0.450 IN |
| Nominal Drum Diameter | 241.000 MM |
| Nominal Drum Diameter | 9.488 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890052340 |
Part Interchanges
CENTRIC 123.62008 Cross Reference
We have 4 alternatives for the 123.62008 by CENTRIC:
Fits Vehicles
- Buick Skylark (1975)
- GMC G1500 (1964-1966)
- Pontiac Ventura (1971-1974)
- Pontiac Firebird (1970-1973)
- Oldsmobile Omega (1973-1974)
- GMC Sprint (1971-1972)
- GMC G15/G1500 Van (1967-1971)
- GMC G1000 Series (1964-1966)
- Chevrolet Nova (1969-1974)
- Chevrolet Monte Carlo (1970-1972)
- Chevrolet Malibu (1964-1967)
- Chevrolet G10 Van (1964-1971)
- Chevrolet El Camino (1964-1972)
- Chevrolet Corvair (1965-1969)
- Chevrolet Chevy II (1964-1968)
- Chevrolet Chevelle (1964-1972)
- Chevrolet Camaro (1967-1974)
- Buick Apollo (1973-1974)
